A Baffle FIBC Bag (also known as a Baffle Bag) is an advanced bulk bag designed to overcome the limitations of standard flexible containers. While traditional bulk bags tend to bulge or lose their square shape when filled, baffle bags incorporate internal fabric panels or string reinforcements sewn into each of the four corners. These baffles help the bag maintain its shape when filled, allowing for efficient side-by-side storage and stable stacking.
|
Type of bag
|
Tubular/Circular/U-panel shape//Rectangular
|
|
Material
|
100% Virgin PP
|
|
Fabric
|
Laminated/Plain/Vent/Conductive
|
|
Size
|
Customized
|
|
GSM
|
110gsm-230gsm
|
|
Color
|
Customized
|
|
Printing
|
Customized
|
|
Top
|
Full open/Filling spout/Top skirt/Duffle
|
|
Bottom
|
Flat/plain/with discharge spout
|
|
Liner
|
Liner(HDPE, LDPE) or Customized
|
|
Lifting loop
|
Cross-corner loops/4 Point 2 Strap lifting loop/Double Stevedore Strap/with belt/Fully belt loop/Loop in loop
|
|
Sewing
|
Plain/chain/chain lock with optional soft-proof
|
|
Ropes
|
1 or 2 around the bag body/customized
|
|
SWL
|
500-2000KG
|
|
SF
|
5:1/6:1/or as the customer’s requirement
|
|
Treatment
|
UV-treated or not UV-treated
|
|
Surface Dealing
|
Coated or plain, printing or no printing
|
|
Usage
|
Storage and packing, Mine, ore, fertilizer, chemical, onion, potato, grain, wheat, maize, rice, peanut, sugar, salt, agriculture, building materials, powder, cement, etc.
|
|
Processing
|
Yarn drawing-Circular weaving/Webbing- Quality inspection- Coating- Film blowing-Cutting-Printing-Sewing-Checkout-Packaging-Transportation
|
|
Delivery time
|
15-30 days
|
|
Certification
|
ISO22000, ISO9001, ISO14001, LABORDATA, etc.
|
|
Remark
|
Please let us know your specific requirements
|
Square Shape Retention – Maintains a consistent cubic form when filled
30% Improved Storage Capacity – Maximizes warehouse and container space
Space-Efficient Footprint – Square design optimizes pallet and storage utilization
Superior Stability – Enhanced stackability reduces tipping risks during transport
Higher Capacity Than Standard Bags – Offers increased volume compared to Tubular or U-Panel constructions
Anti-Static Options Available – Suitable for hazardous or explosive environments
The reinforced structure of baffle bags delivers critical advantages where handling efficiency and safety are priorities:
Easy stacking and storage
Optimized form factor
Enhanced structural integrity
Simplified handling and transportation
Baffle FIBC Bags are ideal for a wide range of dry, flowable materials, particularly finer powders. Typical applications include:
Beans, seeds, wheat, grains
Food ingredients
Sand and fumed silica
Minerals
Resin and petrochemicals
Chemicals
Please note: Baffle bags are not recommended for large, bulky materials with limited flowability. Such products may become caught in the internal baffles, fail to fill the corners properly, and result in unstable loads.
Choosing between a Baffle Bag and a standard FIBC depends entirely on your specific material and application. Baffle bags perform best with finer powders and are widely used in the food, agricultural, and chemical industries. They are also an excellent choice for anyone looking to pack more material within limited space or reduce storage and transportation costs.
